Leírás és Paraméterek
Technical parameters
| Maximum operating pressure | 7.5 MPa (1015 PSI) |
| Flow rate setting | 1 - 300 ml/min, 0.1 ml/min steps |
| Repeatability of flow rate adjusting | ± 1% |
| Accuracy of set flow rate setting | ± 2% |
| Pumping system | two pistons dim. 3/8" in parallel connection |
| Wetted materials | stainless steel, PEEK, ceramic, seals* |
| Power supply | 24 - 36 V DC |
| Control | RS232 |
| Power input | 150 W |
| Dimensions (W x H x D) | 212 x 153 x 338 mm |
| Weight | 8 kg |
| Output capillary outer diameter | 1/8" |
| Input tubing outer diameter | 3/16" |
